Factory Seconds
Item: EX10060434
|Model: MSW-MD60-PRO
Magnetic Drill Machine - 1.680 Watt - 370 r/min - Weldon Shank 19 mm
€589.00
Qty
Discount
Per item
3+
4%
€565.44
5+
8%
€541.88
10+
12%
€518.32
Key features
- High-powered engine with 1.680 watts power
- Comfortable control panel with a seamless rotation regulation, direction of rotation and other operating elements
- Extensive accessories, inside a hard-shell carrying case
- Integrated cooling agent tank
- Extensive safety precautions RCD magnet switch, robust lashing strap, easy-to-access safety switch, two-stage safety activation
- Highly stressable, yet compact construction
Accessories
Delivery details
Returns and warranty
Downloads
Satisfaction all ok
CYBER WEEK ENDS IN
0
d
:
0
h
:
0
min
:
0
s
Similar categories
Technical details
Material
Aluminiumcasting
Colour
Blue
Voltage [V]
230
Power [W]
1680
Drill diameter [mm]
28
Drill chuck
B18 / 3 - 16 mm
Guide system range [mm]
0-165
Screw tap diameter
M25
Built-in level
Yes
Tapping function
Yes
Carry case included
Yes
Safety strap included
Yes
Tank capacity
0.3 l
Diameter of lace drill
60 mm
Cooling tank tube length
500 mm
Electromagnet max. attraction
18000 N
Max. drilling depth with core drill
50 mm
Dimensions (LxWxH)
22.5 x 32 x 57 cm
Weight
17.35 kg
Shipping dimensions (LxWxH)
61 x 52 x 22 cm
Shipping weight
23.9 kg
Delivery package
- Magnetic drill machine MSW-MD60-PRO
- Lashing strap
- 3 rotary handles
- 2 angled screw drivers
- 2 safeties
- Expulsion chock
- Cooling tank
- Drill chuck holder
- Keyed chuck (B18 / 3 - 16 mm)
- Drill chuck wrench
- 2 coal brushes
- MK2 hang up cup / Weldon shank 19 mm
- Carrying case
- Instruction manual
Product Description
Magnetic Drill Machine – 1.680 Watt - 370 r/min – Weldon Shank 19 mm
The magnetic drill machine by MSW is powered by up to 1.680 watts, which makes it a true powerhouse when it comes to working on magnetic surfaces. It does not matter if you need to work in a vertical or horizontal position. The powerful electromagnetic foot keeps the machine safely in its position. The magnetic drill machine is very reliable and a valuable tool for both industrial and commercial metalworking. The machine can be used for drilling, countersinking, thread cutting and ring drilling.
In metalworking, one thing is important above all else: Power. With its 1.680 watts power, the magnetic drill machine by MSW puts its competitors into their place. The seamlessly adjustable rotation speed of up to 370 rpm allows for a drilling with the mobile electrical device as well as lowering, ring boring and core drilling. When threading, you can reverse the direction of rotation. It prevents the freshly cut thread from being damaged when unscrewing the tap.
The construction of the machine allows for a simple and precise operation. The drilling depth from 0 to 165 mm can be precisely set with the three-arm rotary control. The integrated water level means that exact 90° angles are easily achieved and held.
The drill has a very practical integrated cooling agent tank. For simple tasks, the 300-millilitre tank can be filled with tap water. For more demanding jobs, a special coolant or cutting oil is used. This extends the service life of the drills and minimises maintenance.
With a weight of around 20 kilograms, the magnetic drill is heavy enough to produce precise results. At the same time, it is not too heavy to be used on the move. The compact construction and the connecting 2 m cable allow you to use the machine for work on bridges, cranes, ships and other construction sites where magnetic metals are processed. In addition to the industrial sector, companies in the metalworking industry such as locksmiths and car repair shops also benefit from this tool.
Not only the performance of the magnetic drill machine is important, but also its operational safety. With a maximum attraction of 18.000 Newton (the equivalent of over one ton), the magnet also works on thin workpieces which require a high attraction. Additional security is provided by the lashing strap (included in the delivery), which prevents damage to the workpiece and injury to the user, for example in the event of a power failure.
The RCD magnetic switch is another valuable safety feature. If the device is accidentally switched on after a power failure or a disconnect from the grid, the engine will not start. Another operation is only possible when the magnetic switch is set.
The composition of the accessories is a testimony to experience and expertise. A drill chuck for holding shafts with a diameter of up to 16 mm is included in the delivery, as well as a Weldon shank, a coolant tank, assembly tools and many other useful accessories. Replacement carbon brushes and fuses are included in the delivery. The set comes in a robust hard-shell transport case.
